Archiv

Medientechniknews

Console: Changes to previous version————————— Added support for UCD-424. Added Firmware Update capability over USB. UCD-400, UCD-424: Added SSC support. Added support for HDCP 2.3 facsimile keys. UCD Console: Fixed bug in Pattern generator that caused all error messages to not show up. UCD Console: Fixed bug which caused incorrect H-Active size being sent out from DP TX after disabling DSC. UCD Console: Fixed bug which caused incorrect colorimetry to be used after disabling DSC on DP TX. UCD Console: Fixed issue which caused the Sink DUT DSC test CRC calculations to not properly follow the selected mode. UCD Console: Fixed HPD Event decoding in Event Logger. UCD Console: Removed „From“ and „F“ columns from Event Logger. UCD Console: Removed faulty „From“ column from Event Logger report generator.
Die hohen Datenraten, die bei der Übertragung von Videosignalen in medizinischen Netzwerken auftreten, brachten die herkömmlichen 1 Gbit/s Netzwerkisolatoren an ihre Grenzen und führten oft zwangsläufig zum Einsatz von Lichtwellenleitern.Mit der 10 Gbit/s Baureihe EMOSAFE EN-66 lassen sich diese Umwege vermeiden und trotzdem alle Anforderungen der DIN EN 60601-1 (3. Ausgabe) erfüllen. Diese Isolatoren sind einsetzbar in klassischen Netzwerken (inkl. SDVoE) und bei HDBaseT-Anwendungen.Anmerkung: wenn Sie medizinische SDVoE-Komponenten einsetzen, und diese mit dem entsprechenden Switch verbinden, degradieren Sie das ganze System auf ein nicht-medizinisches Level im Sinne der elektrischen Sicherheit. Abhilfe schafft die Nutzung von 10 Gbit/s Isolatoren in jeder Verbindung, oder die Nutzung „medizinischer“ 10 Gbit/s Switche, allerdings ist uns keiner bekannt … 10 Gbit/s Netzwerkisolatoren10 Gbit/s Netzwerkisolatoren: EN-66S – Medizinischer 10 Gbit/s Netzwerkisolator für SnapFit-Montage –
DPA-400 is a very valuable tool for monitoring the AUX Channel handshake between the source and the sink and revealing any root causes of possible failures. It can be placed between DP Source and upstream port of DUT or between downstream port of the DUT and DP Sink. DPA-400 GUI detects and parses all DPCD locations used in all DP versions from 1.1 to 2.0. It decodes as well the HDCP 1.3 and 2.2/2.3 messages and DP Sideband Channel Communication messages. The activity of the Hot Plug Detect (HPD) signal and optional user defined input signals will also be tracked and time stamped. DPA-400 AUX Channel Monitor is compatible also with DisplayPort Alternate Mode in USB Type-C interface. With the Unigraf provided cable, you can connect the DPA-400
On August 22nd Video Electronics Standard Association (VESA) has approved Compliance tests for DisplayPort 1.4 Link Layer. Unigraf’s UCD-400 is now platform for both DP 1.4 Link Layer and HDCP 2.2 Compliance Tests. For years Unigraf has been a reliable supplier of certified DisplayPort Link Layer CTS test tools. After VESA certified DP 1.2 test tools, Unigraf is now offering DP 1.4 LL CTS Tests approved by VESA.For more information on DP 1.4 Link Layer CTS Tests click here and for more information on UCD-400 click here.
Lange erwartet, endlich ist er da, der Gesamtkatalog aller Unigraf-Produkte aus den Bereichen Video Compliance Test Software und Hardware (DisplayPort, HDMI, USB-C) und Framegrabberkarten. Bei allen Fragen wenden Sie sich einfach an unser Team. Unigraf Gesamtkatalog 2018
ONErack is a universal, powered mounting system that vastly improves rack installation of small devices. tvONE’s patent pending design converts randomly sized, externally-powered devices from any manufacturer into slide-in modules that can be installed quickly and cleanly and serviced easily. Chassis are available in 4RU, 5RU and 6RU and can hold up to 16 modules with up to 2 power circuits each. When using the ONErack Power Supply, each power circuit, can provide selectable power @ 5v, 7.5v, 9v, 12v, 18v, 24v up to 35 watts.  A pass thru is available for custom power sources.  Each ONErack Chassis can include 1 or more Power Supplies that can feed additional chassis, to allow for a clean power solution for all mounted devices.  For service, just slide out a failed
Unigraf compact sized AUX Channel Monitor DPA-400 is now recognizing and parsing also DP 1.3, DP 1.4 and HDCP 2.2 specific transaction and sink DPCD registers. DPA-400 GUI lists all AUX traffic both in a time stamped transaction list and a decoded interpretation of each DPCD read and write. The meaning of each bit is described. The new features can be acquired as an upgrade to all existing DPA-400 units. Please contact dimedtec for Details.
Unigraf video monitor range includes a wide selection of LCD based solutions. Relying on its experience and expert technical knowledge, Unigraf can provide a standard or custom made display to fit your specific needs. Marine and Mobile Monitors Marine certified monitors for displaying navigational or radar data on the bridge of the vessel or the status of the systems in the engine room. Rugged LCD monitors for mobile and light defense applications: ECDIS display Radar display Outdoor display Ship automation Ballast tank levels Defense purposes Map surveillance in high resolution Troup transport vehicles   Bridge Requirements Compliant Wave Series monitors have been type approved for bridge use. They comply with the following standards: MSC.191(79) Performance standards for presentation of navigation-related information on shipborne navigation displays IMO Res. A.694(17)
UCD-323 HDDP Dual enables testing of HDMI 2.0 and DP 1.2 sinks, sources and repeaters. Combining the reference source and reference sink functionality in one unit is considerably simplifying the functionality test set-up. UCD-323 is compatible with Unigraf Test System, UTS. Combined with the UTS Test Cases, UCD-323 is a functionality testing tool with ready test routines for all support interfaces. http://www.dimedtec.de/audio-video/Unigraf-UCD-323-HDDP-Dual-USB-30-connected-video-test-module-with-4K-inputs-and-outputs-incl-TSI-Basic-Test-Software-Set
Sie kennen das Problem moderner Daten- und AV-Installationen, oft werden unzählige verschiedene Hardwarekomponenten benötigt. Nur leider ist der Platz oft begrenzt und diese hohe Dichte verursacht auch erheblichen „Kabelsalat“. Für dieses Problem gibt es eine Lösung, Hardwarekonzentration! Wir integrieren all Ihre Komponenten in einem Gehäuse, mit Anschlussfeldern und Beschriftungen nach Ihren Wünschen. Oder Sie haben viele externe Komponenten, die alle ein eigenes Netzteil benötigen. Dann lassen Sie sich ein passendes Netzteil konfigurieren, mit all den Spannungen die Sie benötigen. Und das alles für die Medizin und die Industrie. Im folgenden Beispiel mussten folgende Komponenten integriert werden: 4 Videoscaler 4 galvanische Trennungen 4 DVI-Extender Sender 1 DVI-Extender Empfänger 2 USB-Extender Empfänger passende Stromversorgung Das Ergebnis sehen Sie hier:
